Dragon Canyon Pro
INTEL® NUC 12 PRO X
NUC12DCMv7 Full
- Intel® Core™ i7-12700
- Cores 12, Threads 20
- Intel® UHD Graphics 770
- Passmark Coming Soon...
Contact Sales
NUCNUC12DCMv7 INTEL® NUC 12 PRO X
Base CPU Frequency
2.1GHz
Turbo Boost
4.9GHz Turbo
Cores & Threads
Cores 12, Threads 20
Graphics
Intel® UHD Graphics 770
Max Memory
64GB
Networking
1x Marvell 10GbE LAN, 1x Intel 2.5Gb LAN (i225-LM), Intel Wi-Fi 6E AX211+ Bluetooth v5.2
Max Resolution
7680x4320
Video Output
1x HDMI 2.0b port, 2x Thunderbolt 4 (DP 1.4)
I/O
2x Thunderbolt 4 ports, 7x USB 3.2 Gen2 Type-A ports, 1x USB 3.2 Gen2x2 Type-C, 1x 3.5mm audio jack
A New Gold Standard for Business Workstations
Sporting the all-new 12th Gen Intel® Core™ i7-12700 desktop processor, with support for a full-sized graphics card, 64GB of ECC RAM, and three M.2 sockets for up to 18TB of NVMe storage, Dragon Canyon Pro has ample performance and capacity to meet all your workstation needs. All three of the storage sockets on Dragon Canyon Pro are Gen4 compatible, allowing you to maximize your read/write speeds with the latest in NVMe technology, greatly increasing your business efficiencies. Dragon Canyon Pro packs 650W of performance in a compact 8-liter chassis making it your versatile package to unlock the new gold standard in business workstations.
Taking your Infrastructure to New Heights
Dragon Canyon Pro is equipped with a 5th generation PCIe x16 slot to support the latest and greatest in GPU technology and an LGA1700 socket for the CPU, allowing you to upgrade your CAD workstations, analysis servers, and automated data augmentation devices, taking your internal IT infrastructure to new heights with increased processor and graphics performance, and higher quality output.
Unlock your IT Potential with Intel®vPro™
Dragon Canyon Pro helps you keep deployment times short and maintenance overhead low with Intel® vPro™ Technology, allowing secure remote management of your Intel NUC fleet from anywhere. Save both time and resources by eliminating the need to send staff to perform routine updates or software adjustments locally, allowing you to focus on the things that matter most to your organization.
- Intel® Core™ i7-12700
- Intel® UHD Graphics 770
- Dual channel DDR4-3200 SODIMMs, max 64GB
- 3x M.2 SSD slots
- Intel Wi-Fi 6E AX211+ Bluetooth v5.2
- 650W 80+ Gold internal power supply
- USB 3.2 Gen2x2 Type-C
- USB 3.2 Gen2 Type-A
- SDXC slot with UHS-II support
- 3.5mm stereo headset jack
- Kensington lock
- 6x USB 3.2 Gen2 Type-A ports
- Marvell 10GbE LAN
- Intel 2.5Gb LAN
- HDMI 2.0b port
- 2x Thunderbolt 4 (DP 1.4)
Product Brief
